Chemical Process Pumps & Filtration
KBE Metallic Centrifugal Pumps
Self-priming, centrifugal, vertical in-line and air-cooled thermic fluid pumps in cast steel, stainless steel, Alloy 20 and Hastelloy.
- Material of Construction
- Cast steel / SS-304 / SS-316 / SS-316L / Alloy 20 / Hastelloy
Overview
Metallic centrifugal pumps for chemical process duty, available as self-priming, end-suction centrifugal, vertical in-line self-priming and air-cooled thermic fluid models.
All models are available in cast steel, SS-304, SS-316, SS-316L, Alloy 20 and Hastelloy.
Models
- Self-priming pumps — flow up to 100 LPM, head up to 60 MWC, power up to 5 HP, 1450 RPM, up to 180 °C
- Centrifugal pumps — flow up to 800 m³/hr, head up to 140 MWC, power up to 150 HP, 1450 / 2900 RPM, up to 180 °C
- Vertical in-line self-priming pump — flow up to 20 m³/hr, head up to 35 MWC, power up to 7.5 HP, 1450 RPM, up to 180 °C
- Air-cooled thermic fluid pumps — flow up to 120 m³/hr, head up to 60 MWC, power up to 40 HP, 2900 / 1450 RPM, up to 350 °C
Technical Specifications
- Material of Construction
- Cast steel / SS-304 / SS-316 / SS-316L / Alloy 20 / Hastelloy
Flow, head, power and temperature vary by model — see Models above.
